🔧 Upgrade your vintage windows with precision and style!
The Andersen Straight Arm Operator (Left Hand) 9-3/8" in stone color is a corrosion-resistant, precision-engineered replacement part designed for primed wood casement windows manufactured between 1979 and 1989. It includes a black nylon shoe, cover, and screws for easy installation, and fits left-hand windows with the lock on the left side from the interior. Handle sold separately.
| ASIN | B00079RDRM |
| Batteries Included? | No |
| Batteries Required? | No |
| Best Sellers Rank | #233,969 in Tools & Home Improvement ( See Top 100 in Tools & Home Improvement ) #293 in Window Locks & Latches |
| Brand | Andersen |
| Color | Stone |
| Customer Package Type | Standard Packaging |
| Customer Reviews | 4.5 4.5 out of 5 stars (679) |
| Date First Available | January 13, 2006 |
| Exterior Finish | Wood |
| Finish | Polished |
| Hand Orientation | Left |
| Handle Attachment Mechanism | Separate Handle Attachment Required |
| Handle Material | Nylon, Wood |
| Head Style | philips |
| Included Components | Screw |
| Installation Method | Screw-In |
| Is Discontinued By Manufacturer | No |
| Item Package Quantity | 1 |
| Item Weight | 1.25 pounds |
| Item model number | 1361308 |
| Lock Type | Key Lock |
| Manufacturer | Andersen Windows |
| Material | Nylon |
| Number Of Pieces | 1 |
| Part Number | 1361308 |
| Product Dimensions | 20"L x 6.25"W |
| Projection Distance | 9.38 Inches |
| Size | 9-3/8" Arm Length |
| Special Feature | Corrosion resistant |
| Special Features | Corrosion resistant |
| Specific Uses For Product | Commercial/Residential |
| UPC | 716289557615 703765947725 785577213151 |
| Unit Count | 1.0 Count |
J**E
Perfect, over-priced replacement
My 30-year-old Andersen window's arm broke and I purchased this because it seemed like the safest choice. I watched the video on Andersen's website and the replacement was easy and effective. However I agree with others who say it's overpriced. I cannot speak to its longevity - it feels looser than my old one but otherwise operates as it should.
D**M
Fits and easy install
Why did you pick this product vs others?: Availability
B**N
High quality
I installed this and I window due to the old one that was installed with the original window in 1979 becoming defective. The new one was made of high-quality materials worked extremely well. It’s been in my house for three years. The window is not open and closed frequently. However, there in zero issues with the item. I would purchase again.
V**R
Perfect drop-in replacement for old failed operator
This part is ridiculously overpriced and poorly designed. Nevertheless, it is a perfect drop-in replacement for older (70s-90s) Andersen casement windows. Note that this is a 9-3/8" left-handed straight arm operator. Facing the window from the inside, the arm swings to your left, the window hinge is on your right. The right-handed (left-hinge) version is part #1361310. This replacement has several differences from the original it replaced -- the new track has no recess, shoe is mounted from the other side of the arm, the cover has screw holes and a lip that goes under the wood sill cover. Despite these differences, it replaced the original without modifications. The new arm will work with the old track if desired. This part includes the operator, arm with shoe, track, cover, and hardware. The crank handle is not included, so you'll want to save your originals or buy new ones.
T**S
I used my bench top jig saw and a hand file to carefully remove the plastic obstructions from the new operator cover to achieve
The new operator replacement fits and performs perfectly. However, the new supplied operator cover did not fit into my 1975 "old style" window sill stop. I tried to use the original operator cover but it doesn't fit over the new operator. I had to choose between trimming wood from the sill stop or trimming plastic from the new operator cover. There is very little wood where I would have to trim the sill stop for the additional clearance needed to fit the new operator cover so I opted to trim the plastic operator cover. I spent about an hour modifying the new operator cover to fit into my original sill stop. I used my bench top jig saw and a hand file to carefully remove the plastic obstructions from the new operator cover to achieve the perfect fit. The second operator installation went much quicker having already established what had to be trimmed from the new operator cover. New replacement sill stops are available. I don't know if replacing the old sill stop with a new sill stop enables the new style operator cover to fit the new sill stop without any additional modification. Replacing a sill stop is much easier than trimming the new operator cover and a better choice for ease of repair.
D**E
Andersen Arm Operator
Great replacement part for old Andersen windows. Perfect fit and quick delivery.
J**D
Easy install
Worked great on our Anderson window. Easy install working good so far, if it lasts as long as the original then durability will be good. Thought it was a bit over priced.
A**R
Screw heads are a different color.
Works fine, but screws are a different color.they should match the rest of the product. This was very expensive so it all should match. Doesn’t come with handle, sold separately seems like they put in any old screws that were laying around. Very sturdy and well built.
