5 Pcs Front LED Grill Lights Compatible with Ford Bronco Accessories 2021 2022 2023 2024 2025 2/4 Door Badlands Wildtrak Everglades & Stroppe Edition (Amber Light with Amber Shell)

Easy to install, looks great, very bright and visible, definitely great value. And fits nicely.

I didn't want to jankily power these with a fuse pass through like they are supposed to be (I'll explain how!), so I wired them into Aux6 which is one of the lower Amp aux switches if you have the Aux Switches option. Video instructions were very cleat and step by step, install was very easy! Overall this was an awesome kit in design and implementation, highly recomend! To wire to Aux6 1)There is a purple wire [pic 2] up top by the grill in the middle on the headlight harness, you'll want to strip the fuse connector off of the end of the light kit and connect the lights to that purple wire once they are clipped in and all installed as per that video. 2) There are 6 wires coming out close to the fuse box on the drivers side back corner of the engine bay. Those are wired to the Aux switches and hot (Aux6 is the Yellow/orange). There are 3 other wires in a separate loose bundle that come out close to that location (the purple one is the same wire that is in the front of the Bronco grill) they are separately run to the front of the grill, and then I think to the glove compartment. You will want to connect the purple wire that is down there from the small bundle of 3 and connect that to the yellow/orange from the bundle of 6 [Pic 3] 3) Make sure you find a good ground for ground end on the lights. I had mine hooked onto an aluminum bolt which obviously wouldn't work and moved the ground to a bolt close to the battery terminal. I also included a screen shot [pic 4] of the Aux wiring diagrams and some info I got from a helpful chap on the forums as Ford didn't give any of us a hard copy of the owners manual. Now these lights are wired to Aux6! You can leave that Aux flipped on, it will not draw power when the vehicle is off and is powered when the ignition is on and/or the vehicle is started. Now you preserve the integrity of the fuse box water seal, can turn off the lights of you wish, and have a very satisfying switch to play with. Hope this is helpful!

Looks great, very easy installation. Only con is the wires are massive. It’s very hard to hide them

Easy install, look good. They are quite bright. Connect to Aux 6 and it works great.

They look great. However, when I wired it to the recommended fuse slots: the car wouldn’t start; in another slot, I had system failures but I was probable doing something wrong. I ended up using aux 6 and that worked. For me, the hardest part of the whole installation was making sure I got the wiring correct. Seemed easy but gave me some issues. Follow the directions and it will work.

I installed the 5 Pcs Front LED Grill Lights today, and honestly, it was one of those projects that had a little bit of everything — tedious, fun, and satisfying all in the same day. The wiring took some patience, and lining everything up perfectly tested my attention to detail, but once those lights clicked on… wow. Totally transformed the look of my front end! The brightness is spot on — not blinding, but just the right amount of glow to give the grill that aggressive, clean, custom look. The build quality feels solid, and all the connectors fit snugly. Like most installments I’ve read, it is easier to hard wire to the AUX 6 switch. This way you can turn them on and off whenever you want. So, if you enjoy tinkering and want a rewarding DIY that pays off the same day, this is it. Just take your time, maybe grab a cold drink for the process, and enjoy watching your truck come to life when you flip that switch. Highly recommend — 10/10 upgrade for anyone who loves their rig!

they look great! However, the video install by GarageBoys on YouTube makes the job easier. But DO NOT install in the fuse holder shown on the video. The video shows replacing the 20A fuse with the included fuse attachment (10A) from the lights wiring harness. If you do this - our Bronco will not start and the starter will just keep turning over. I figure it is because of the fuse size going from 20A to 10A. . Easy fix is to just attach the red wire from the wiring harness (you will have to cut and strip the wire - you won't need the fuse plug in attachment included with the wiring harness from the LED lights )and to the pre-wired Yellow/Orange wire that operates AUX 6 switch above the mirror in the cab of your Bronco. (all 6 AUX switches are pre-wired and are located between the fuse box and the cab) The Aux switches only work when the Bronco is running so you can just leave the switch in the on position and these lights will come on whenever the truck is running. Hope this helps

Doesn't fit stock grill.

Easy and fast install. Find YouTube videos on how. I love the look. Best to connect with the camera fuse. Turns on when the truck does. Love it. Don't see them when off too

Wanted that Bronco Raptor look , bought these and they work and look great. They come in with my day time running lights and when the lights are on. Great price and quality was really good.

Mala calidad y vista, no es igual al que ofertan, vienes más chico

Super easy install, took 30 min because I had to remove the brushguard before accessing the grill. I attached the wire for the marker lights to the wires for the rough country amber DL so they turn on at the same time using one of the accessory switches. They match the color and intensity as the fog lights. I purchased the smoke version so they are barely noticeable when off. Also, because the brush guard covers the top row of the grill, I used the second row for the lights which is why I used only four lights, since the spacing is offset from the top and no center opening. Lights are well made and strong, not cheap, the harness is simple to hide so wires are tidy.

Looks fantastic, I used fuse #22 which is for 360 camera on my 2025 badlands. Easy to do pretty much like video. I had to notch the cover of the fuse box so wire would not pinch but otherwise all good. Works when I turn on the car and turns off when I turn off. No need to use Aux switch.
